What is Ecobond?
The industry-leading Resin Modified Bitumen Emulsion (RMBE). A high-performance, environmentally sustainable solution for long-term road structural integrity.
Technical Architecture
Ecobond is a sophisticated Resin Modified Bitumen Emulsion (RMBE) formulated for soil stabilization and dust suppression. Unlike conventional bitumen, our proprietary formula integrates high-tensile resins that create a cross-linked molecular structure when cured, effectively creating a semi-rigid pavement layer.
As specified in COTO 2021 (Listing 4.4.5.4), this "Cold-Mix" technology allows for application at ambient temperatures. It is further recognized by SANRAL / SAPEM 2013 as an endorsed method for sustainable road construction, offering performance that rivals traditional hot-mix asphalt in load-bearing capacity and shear strength.
Regulatory & Certification
Agrément SA Certified
Certified for use in South Africa under standard specifications for innovative road products.
Dept of Public Works
Compliant with National Standard Specifications for infrastructure works.
Head-to-Head Comparison
Independently verified performance against conventional alternatives.
| Criteria | Ecobond | Bitumen | Lignin |
|---|---|---|---|
| Total Cost of Ownership | arrow_downwardLower | Higher | Medium |
| Temperature Sensitivity | check_circleNone | High | Medium |
| Sticks to Vehicles | check_circleNo | Yes | No |
| Deep Surface Penetration | check_circleSuperior | Surface Only | Partial |
| Application Frequency | arrow_downwardLow | Low | High |
| Water / Trucks Required | arrow_downwardMinimal | Medium | High |
| Environmental Leaching | check_circleZero | Low | Yes |
| HSE / Mining Compliance | verifiedFull | Partial | Partial |
| In-situ Materials Reuse | recycling100% Reuse | Requires Import | Partial |
| Local Skills Development | schoolHigh Impact | Minimal | Minimal |
| Increased Wet Strength | show_chartSignificant | Moderate | Low |
Product Ecosystem
Specialized formulations for diverse infrastructure requirements.
layers Surfaced / "Tar" Road Solutions
BituForce
High-performance road rehabilitation/recycling (TG2 2009 BSMs). Suitable for base course use in all classes of surfaced roads.
EBase
Elastic material designed for rehabilitation and new "Cemented" base type designs.
BituMod
Engineered to improve the Indirect Tensile Strength (ITS) of granular pavement layers.
scatter_plot Gravel / Unsurfaced Solutions
SprayOn
Non-temperature sensitive bitumen emulsion for precision dust inhibition and erosion control.
DuraGrav
A powerful combination of BituMod and SprayOn for long-term gravel road structural improvement.
BlackRock
Using mine dump rock to form dust-resistant, semi-permanent wearing courses.
Official Certification
Ecobond is fully accredited and tested at the highest institutional levels.
-
verified
Agrément SA Certified (2015/496)
Official "Fit for Purpose" certification for the building industry and road infrastructure.
-
gavel
COTO 2021 Listing
Classified under 4.4.5.4 as an approved "Non-traditional soil stabilizer".
Technical Documentation
Access the full technical overview, including structural engineering manuals and multi-year cost comparison audits.
download Download Full PDF (13 Pages)Technical Specifications
Reference: DOCUMENT_2 / EMA-TECH-SPEC
| Property | Test Method | Ecobond Range | Compliance |
|---|---|---|---|
| Residue by Distillation | ASTM D244 | Min 62.0% | check_circle |
| Viscosity (Saybolt-Furol) | ASTM D88 | 20 - 100 sec | check_circle |
Engineer Your Road's Future
Download the complete technical data sheet or request a pilot application study for your site.
